Manufacturer:General Electric
Model:DS3800NEPA1D1C
Compatibility:For Mark IV Speedtronic series
Dimensions:Vertically bulkier due to two 44B379508-G02 modules from Raycom Electronics
Connectors:Six-pin, seven-pin, eight-pin connectors in various configurations; one multi-pin terminal connector
Components:One jumper switch, four integrated circuits, four potentiometers, multiple capacitors, resistors
The DS3800NEPA1D1C, manufactured by General Electric, serves as a crucial component in the Mark IV turbine control system, ensuring reliable power supply to the motor exciter. Its design incorporates robust engineering principles to enhance durability and efficiency. Key features include its significant height due to the inclusion of two 44B379508-G02 modules from Raycom Electronics, strategically placed near the center of the board. This configuration optimizes performance and stability during operation.
The board is equipped with multiple connectors that facilitate easy integration with other components of the turbine control system. These include six-pin, seven-pin, and eight-pin connectors arranged in various configurations, ensuring seamless connectivity. Additionally, it features a multi-pin terminal connector located in the upper left corner, further enhancing its versatility and ease of use.
Designed with meticulous attention to detail, the DS3800NEPA1D1C integrates essential components like four integrated circuits, four potentiometers, and numerous capacitors and resistors. Notably, it includes two 10W 71Ω 5% resistors and nine large banded metal film resistors, which contribute to its robustness and efficiency under varying operational conditions.
This power board is also equipped with a jumper switch, offering users the flexibility to adjust settings between ‘rev’ and ‘nr’ modes. Such adaptability ensures that the DS3800NEPA1D1C can be customized to meet specific operational requirements, making it an indispensable component in any turbine control setup.
By integrating advanced technologies and materials, the DS3800NEPA1D1C offers unparalleled reliability and performance. Its compatibility with the Mark IV turbine control system underscores its role in safeguarding against unsafe operating conditions and enabling automated procedures such as startup, shutdown, and cooldown. With its innovative design and proven track record, the DS3800NEPA1D1C stands out as a premier choice for industrial applications requiring precise and dependable turbine control.
