Power Dissipation:0.32 Watts per channel, 1.024 Watts for the entire module
Operating Voltage:12V to 24V DC for relay operation
Current Consumption:Max 20mA for relay activation
Relay Contacts:Silver alloy double break contacts, rated at 1A/24VDC
Isolation:Opto-isolated for enhanced safety and signal integrity
Temperature Range:-20°C to +60°C for robust operation under various conditions
Connection:Screw terminal block for easy installation and configuration
Dimensions:90mm x 110mm x 35mm (WxDxH), compact design for space-saving applications
Engineered for durability and precision, the Schneider TSXDSZ32R5 offers exceptional performance in industrial control systems.
Each relay is rated at 50VA, providing robust switching capabilities for a wide range of load types.
With its terminal block included, setup and integration are simplified, ensuring a quick and easy installation process.
Operable within an extended temperature range from -20°C to +70°C, making it suitable for demanding industrial environments.
Built with an IP20 enclosure, it offers basic protection against dust and splashes, safeguarding the internal components from external contaminants.
Efficient power consumption ensures minimal energy use, contributing to sustainable operations without compromising on performance.
